Kent USA TRD-920A - Radial Drill Press w/ Box Table Cube
Have one to sell?
$18,500.00 USD
ConditionNew
New
New Radial Drill Press Model TRD-920A -Manual Clamp System-
* 6 Spindle Speeds & 3 Feed Rates
*Centralized Single level Control for Forward & reversal of spindle
* Ultra Low noise
*Light & handy to operate
8 Safety overload
*Auxiliary Dial for Spindle Feed Depth
STANDARD ACCESSORIES:
* 1pc. Work Table Cude
*1Pc. Drift
1pc Adjustable Wrench
*1 pc Coolant
1Pc Work-light
Max Drilling Diameter: 1.97" Castings/ 1.25" Steel
Distance Between Spindle end & column: Max: 37.4" / Min 8.7"
Distance Between Spindle End & working Surface of Base Plate: Max: 47.6"/ min 13.8"
Spindle Taper: MT # 4
Range of Spindle Speeds; 88,154,282,455,796,1500 RPM ( 6 Steps)
Diameter of outer Column: 8.26"
Length Of Arm: 39.7"
Table Size: 24" x 17.5" x 15ft
Spindle Motor: 2HP- 220/3/60 Electrics
Net Weight :2750 Lbs
Gross Weight : 3-80 Lbs
Standard Accessories: Work Table Cube-
Adjustable Wrench
Drift Pin
Coolant
Work Light
